The Semi-Flexible solar panel is the perfect versatile energy companion for mobile applications. The thin profile provides low wind resistance and its extremely light weight makes it well suited to be used on yachts, boats, RVs, 4wd vehicles etc.
Each cell is tested and graded for power, low light performance and being free from micro cracks before going into module production. In-line monitoring is performed for pre and post lamination cell testing and laminate stability. The module design incorporates a superior 7 layer lamination process with a moisture protected border for trouble free performance over the module life.
• High efficiency Monocrystalline Cells.
• Ultra-thin & light weight.
• Outstanding electrical performance in higher temperatures and low irradiation.
• Robust moisture ingress protection.
• Rigid, waterproof junction Box.
• High performance Fluro Ethylene top film.
Please click and read Solar panel warranty policy
Technical Specifications:
Item
|
Specification
|
Description/Remark
|
Model
|
AT-SEMIFLEX-MONOSOL-24-200WV01
|
200W 24V Semi-Flexible Mono-crystalline Solar panel
|
Maximum power rating
|
Pmax 200 Watts
|
|
Solar Panel dimensions
|
L-1600mm x W-665mm x H-3mm
|
|
Tolerance on power output
|
+/- 3.0 %
|
|
Current at max power
|
Imax 5.50 Amps
|
|
Voltage at max power
|
Vmax 36.36 Volts
|
|
Short circuit current
|
Isc 5.83 Amps
|
|
Open circuit voltage
|
Voc 42.88 Volts
|
|
No of cells
|
​64
|
|
Cell Efficiency
|
21.80%
|
|
Temperature Range
|
-40℃ to +80​℃
|
|
Weight
|
3.6kg
|
Features:
The Semi-Flexible solar panel is the perfect versatile energy companion for mobile applications. The thin profile provides low wind resistance and its extremely light weight makes it well-suited to be used on yachts, boats, RVs, 4wd vehicles etc.
Each cell is tested and graded for power, low light performance, and being free from micro-cracks before going into module production. In-line monitoring is performed for pre and post-lamination cell testing and laminate stability. The module design incorporates a superior 7-layer lamination process with a moisture protected border for trouble-free performance over the module life.
• High efficiency Monocrystalline Cells.
• Ultra-thin & lightweight.
• Outstanding electrical performance in higher temperatures and low irradiation.
• Robust moisture ingress protection.
• Rigid, waterproof junction Box.
• High performance Fluro Ethylene top film.
