36V 20A AC-DC Lithium LiFePO4 Battery Charger
🛒 Online Only
or
Amptron 36V 20A AC-DC Lithium LiFePO4 Battery Charger
Please note that the we have sold out this charger due to high demand. The updated expected delivery date is ~21/05/2026 across Australia.
AMPTRON® Lithium Iron Phosphate (LiFePO4) battery chargers are state-of-the-art battery chargers with a charging profile specifically designed to charge and maintain Lithium Iron Phosphate (LiFePO4) batteries, and can safely achieve a 100{08cb6795595cf4832c99cea482302116df95ae2d61a0357cbecbcc60351753c1} State of Charge.
The 36V 20A model charger operates from mains AC 200-260V as input, supplying up to 20A charging output suitable for nominal 36V LiFePO4 battery banks. The charger’s built-in protection technology provides protection against Over Voltage and Over Current output, Short Circuit and Reverse Polarity making it very safe to use. M8 Ring Terminal Connection.
This charger is fitted with a battery wake-up function for recovering batteries that are over discharged or showing 0V.
Free in-store installation is available at our shops, or you can call us for our competitively priced Roadside and Onsite Service.
Product Description
Detailed information and noted points:
|
Item
|
Specification
|
Description/Remark
|
|
Model
|
AT-240-3620ALFPV01 B
|
AC/DC 36V 20A LiFePO4 Battery Charger
|
|
Input Voltage
|
min 200Vac to max 260Vac
|
|
|
Input Power
|
Max 1053W
|
|
|
Constant charge voltage
|
Vdc min 43.5V to max 44.1V
|
|
|
Constant charge current
|
Min 19A to max 21A
|
|
|
Charge complete current
|
Vdc min 1.4A to max 1.8A
|
8{08cb6795595cf4832c99cea482302116df95ae2d61a0357cbecbcc60351753c1} CC
|
|
Ripple voltage
|
500mV
|
|
|
Efficiency
|
88{08cb6795595cf4832c99cea482302116df95ae2d61a0357cbecbcc60351753c1}
|
At full load
|
|
Product Dimensions
|
L-220mm x W-135mm x H-70mm
|
|
|
Weight
|
3Kg
|
Charge Curve:
- ✓ Superior vibration and corrosion resistance
